Why use SQL Frameworks?

Nowadays, the majority of Java backends are using permanent storage, SQL being the most dominant in the market. The default API to communicate with the SQL databases is a specification called JDBC (a bunch of Java interfaces that database developers must implement to let the end users talk to the Database over the wire). The problem is that using plain JDBC is hard for a regular developer because of the following:

  1. All queries must be written manually
  2. The parsing of the data transferred over the wire must be done manually(using ResultSets)
  3. Most of the methods from JDBC API throw checked exceptions which force developers to deal with blobs of try-catch statements
  4. All transactions must be opened and closed manually

Many frameworks help you to deal with the problems mentioned above. According to 2022 survey by Josh Long the most popular frameworks are

  1. JPA(Hibernate or EclipseLink)
  2. Raw JDBC wrappers (such as Spring-based JDBCTemplate class)
  3. JOOQ
  4. MyBatis

All of them solve the problems above in different and unique ways. Today, however, we want to show how FusionReactor can help regular developers monitor databases using the listed SQL and ORM frameworks.

What are ORM Frameworks?

Object Relational Mapping is an acronym that is also known as ORM. It refers to creating a virtual framework that encircles a relational database in an object-oriented language (such as PHP, Java, C#, etc…). The name (ORM) translates as mapping objects to relational tables.

What are ORM Frameworks used for?

The ORM framework/software generates objects that virtual map (like a map of a city) the tables in a database (as in OOP). You, as a developer, use these objects to interact with the database. The main objective of ORM-generated objects is to shield the programmer from having to write optimized SQL code – ORM-generated objects do the job for you.

How to monitor SQL and ORM frameworks using Hibernate

Hibernate is one of the oldest and most mature ORM frameworks in the Java world. Being a JPA implementation, it solves JDBC problems by replacing direct, persistent database accesses with high-level object-handling functions. The most important feature is the mapping of Java classes into corresponding SQL tables. Hibernate uses data manipulation over the Java classes and generates proper SQL statements. To test Hibernate with FusionReactor, we will use a simple SpringBoot project with spring-data as an even higher level of abstraction over Hibernate. Here is the schema:

CREATE TABLE users
(
    ID   BIGINT PRIMARY KEY AUTO_INCREMENT,
    name varchar(255)
);

create table orders
(
    ID      BIGINT PRIMARY KEY AUTO_INCREMENT,
    price   double precision,
    user_id BIGINT references users (ID)
);

One user has many orders. First of all, we need to generate mapping classes for both tables (Lombok will be used to auto-generate POJO methods):

@Entity
@Data
@Table(name = "users")
class User {

    @Id
    @GeneratedValue(strategy = GenerationType.AUTO)
    private Long id;

    @Column(name = "name")
    private String name;

    @OneToMany(cascade = CascadeType.ALL)
    @JoinColumn(name = "user_id")
    private Set<Order> items = new HashSet<>();
}

@Table(name = "orders")
@Entity
@Data
@NoArgsConstructor
@AllArgsConstructor
class Order {

    @Id
    @GeneratedValue(strategy = GenerationType.AUTO)
    private Long id;

    private double price;

    private String name;

    @ManyToOne(fetch = FetchType.LAZY)
    @JoinColumn(name = "user_id")
    private User user;

    Order(double price, String name) {
        this.price = price;
        this.name = name;
    }
}

Next, we need to create a repository interface:

public interface UserRepository extends JpaRepository<User, Long> {
}

Finally, we need to set up the configuration in the property/yml file:

spring.datasource.url=jdbc:h2:mem:testdb
spring.data.jpa.repositories.bootstrap-mode=default

The last two lines allow you to see a formatted SQL generated by Hibernate in the console. Lastly, to test it, we will use a simple Rest Controller that:

  1. Fires Thread.sleep every 5th call to simulate long-running queries
  2. Throws an exception every 3rd call to simulate a business level error
@RestController
@RequestMapping("/users")
public class UserController {

    private final UserRepository userRepository;

    @GetMapping("/save")
    public Long save() {
        final int condition = this.cnt.getAndIncrement();
        if (condition % 2 == 0) {
            TimeUnit.SECONDS.sleep(3);
        }
        final User user = new User();
        user.setName(UUID.randomUUID().toString());
        user.setItems(
            Set.of(
                new Order(12.0, "Banana"),
                new Order(12.0, "Apple")
            )
        );
        this.userRepository.save(user);
        if (condition % 5 == 0) {
            throw new RuntimeException("Business error");
        }
        return user.getId();
    }
}

Let’s send some traffic to the backend and see what insides FusionReactor will give us:

#!/bin/bash
for i in {1..100}
do
  curl http://localhost:8080/users/save
done

(The source code is available here)

Transaction details

First of all, we can list all DB transactions (Transactions -> History)

As you can see, some of them have failed, some took 3000ms (3 sec) and succeeded, and others only took a few milliseconds. Let’s see if FusionReactor can help us to understand why some of these transactions have failed. If you click on the details button (the book icon next to the transaction), you will see the page with all the transaction details:

First, 3 links are HTTP Request specific, so we will skip them now and keep our focus on the SQL part.

JDBC

JDBC page gives you the JDBC summary

  1. The time it took to execute all the queries
  2. All the queries executed by the transaction

A single transaction executed eight queries. This is not the result you would like to obtain from saving a single user with two orders.

Relations

The relations page is particularly useful because it shows you all the queries in a hierarchical order:

Let’s break down this list

  1. Hibernate has generated 3 primary keys from the given sequences
  2. 1 query to insert the user
  3. 2 queries to insert two orders(notice that user_id is null for both orders)
  4. 2 update queries to set user id to newly created orders

(If you want to know how to optimize mapping to decrease the number of queries we highly recommend this wonderful blog post from Vlad Mihalcea)

Event snapshot

Another important page that can help you to understand the root cause of the error is Event Snapshot:

How to monitor SQL and ORM frameworks

This page shows you the following:

  1. The decompiled source code will show you the line where this error has been thrown
  2. The stack trace on the left bottom corner can help you to understand the request cycle
  3. The variables page on the bottom right shows you all the variables which were present before the error (the condition int was 25)

JDBC

All the insides described above were only a part of the Transactions page. FusionReactor can show you much more on the JDBC page:

Settings

The setting allows you to customize the FusionReactor behavior in different ways, starting from settings your threshold for long transactions and ending with query plan generation for long transactions (helps teams to decide whether the particular query will benefit by introducing an index). By default, Spring Boot can generate and print SQL queries generated by Hibernate, and while this feature is useful, it has one limitation, namely, all prepared statement parameters are hidden with placeholders ?. On the other hand, as you have seen previously, FusionReactor shows the queries with all corresponding SQL arguments. While this feature can be helpful in local development, where you can directly copy the SQL statement and paste it into your RDMS of choice to make some tests, the feature can be dangerous in the production environment leaking user credentials when customers are trying to log in to your application. We highly recommend disabling this feature in production which can be done within the Setting page.

Longest transactions

One of the main differences between the Longest Transactions in Request and JDBC pages is that the JDBC one only shows you how long each SQL query took:

As you can see, there are no transactions that took 3 seconds because Thread.sleep what we call in the Controller level is not a part of the query. Another thing is that all transactions in this list have succeeded; even though Java throws an error, it doesn’t affect whether the query itself will fail. As an example, let’s change the schema a little and make the order name (name varchar(255) unique) to be unique. In this case, if you try to rerun the same load test, you will see that some transactions have failed:

How to monitor SQL and ORM frameworks

As always, clicking on the details page will show you Event Snapshots with detailed information.

Graphs

To better visualize the JDBC statistics, FusionReactor provides two graphics:

  1. Time graph
  2. Activity graph

The time graph shows the historical average durations of the following JDBC requests:

  1. Completed
  2. Active
  3. Failed

The time interval is configurable, and all the transactions are persisted. The activity graph shows you the counts for the listed requests. Consequently, it can help you to visualize the peak traffic on your websites.

Database

Last but not least is a Database page which shows you a nice break-down of all JDBC activities using pie charts:

The pie charts show you

  1. Total time by queries
  2. Total time by tables
  3. Query counts by operation
  4. Query counts by table

Metrics

One of the main metric types supported by JVM is JMX. Configured JMX beans can be monitored and reconfigured on runtime. One of the most essential parts to monitor in backend apps is database connection pooling. By default, Spring preconfigures the Hikari connection pool, and by adding this line to your config file spring.datasource.hikari.register-mbeans=true it will generate corresponding MBeans that you can see on the FusionReactor Metrics page:

How to monitor SQL and ORM frameworks

All the settings are configurable and can be monitored using the start icon. The metrics then can be exported to CloudWatch if you are using AWS infrastructure.

Hibernate pitfalls

Hibernate as a Framework has a deep learning curve. There is a lot of reflection manipulation going on under the hood. In Spring Boot, by default, the database transaction is opened on the controller level. Why does it happen? If you load an entity with a lazy collection and then want to use the collection, the session at the controller level will fire a separate SQL query to fetch the data for this collection from Database. The problem here is that database transactions must be opened once they are required (preferably in the Service layer). Otherwise, the long-running transactions will force the connection pool to create new DB connections to serve new users. To disable this behavior you need to pass this line into your config file spring.jpa.open-in-view=false. Let’s rerun the load test. If you check the JDBC history, however, you won’t see any anomalies. But if you open the Transaction Details  Transactions->History page and then go to Relations to see the transaction Breakdown you will notice that Hibernate has opened 3 separate transactions instead of 1:

To fix this problem, add @Transactional annotation on top of the save method.

How to monitor SQL and ORM frameworks using MyBatis

As we have seen, Hibernate simplifies the persistent layer. However, the developer must understand what’s going on under the hood to optimize the default Framework’s behavior. On the other hand, there is another popular Java Framework that doesn’t do a lot of “black magic” under the hood, namely MyBatis. According to documentation

MyBatis is a first class persistence framework with support for custom SQL, stored procedures and advanced mappings

The developers who use MyBatis have full control over the SQL queries using a user-friendly XML or an annotation-based API (with an introduction of multiline Strings in java 14, the Annotation API should be preferred). Let’s rewrite the previous example using MyBatis. First, we need to eliminate all JPA-specific annotations from Entity classes. Next, we have to write SQL on our own using XML files. For this example, we will rewrite the Repository class that saves the user with corresponding orders (Code examples are available here). Here is the Mapper class:

@Mapper
public interface UserMapper {

    void saveUser(User user);

    void saveOrders(@Param("orders") List<Order> orders, @Param("userId") long userId);

    default void saveUserWithOrders(User user) {
        this.saveUser(user);
        this.saveOrders(user.getOrders(), user.getId());
    }
}

and here is the corresponding XML file:

<mapper namespace="com.fusion.reactor.UserMapper">

    <resultMap id="UserResultMap" type="com.fusion.reactor.User">
        <id column="id" property="id"/>
        <result column="name" property="name"/>
    </resultMap>

    <insert id="saveUser" parameterType="com.fusion.reactor.User" useGeneratedKeys="true" keyProperty="id" keyColumn="id">
        INSERT INTO users (name)
        VALUES (#{name})
    </insert>

    <insert id="saveOrders" parameterType="map">
        INSERT INTO orders (
        price,user_id,name
        )
        VALUES
        <foreach collection="orders" item="order" index="index" open="(" separator="),(" close=")">
            #{order.price},
            #{userId},
            #{order.name}
        </foreach>
    </insert>
</mapper>

As you can see, we explicitly wrote two queries, first to save the user and second to save a list of orders. No autogenerated queries and no automapping as in Hibernate, and everything has to be done manually. Let’s rerun load tests and see the JDBC transaction history.

FusionReactor will show you that MyBatis generated queries that you specified with all the parameters displayed, so you can verify that mappers are working as expected Going to the Relations page in transaction detail for one of the requests, we can see that a single request used 1 transaction, and 2 JDBC queries:

How to monitor SQL and ORM frameworks

The MyBatis plugin for IntelliJ has language server support to write type-safe XML files. However, if you want compile-time support there is another framework to consider.

How to monitor SQL and ORM frameworks using JOOQ

The last SQL framework that we will cover today is JOOQ. According to the official website

jOOQ generates Java code from your database and lets you build type safe SQL queries through its fluent API.

JOOQ is different from the two previous frameworks because it generates java classes from SQL tables on compile time. All compiled java classes are part of the classpath and can be accessed during development. As the latest Spring-Boot-jooq starter does not support H2 we will use Postgres as an RDMS (source code is available here). First, we need to run mvn clean install to generate java classes. Next, we will write the same query that saves the user and two orders but using JOOQ API:

@RestController
@RequestMapping("/users")
public class UserController {

    @Autowired
    private DSLContext dslContext;

    @GetMapping("/save")
    public long save() {
        final Record1<Integer> id = this.dslContext.insertInto(Tables.USERS)
            .columns(Tables.USERS.NAME)
            .values(UUID.randomUUID().toString())
            .returningResult(Tables.USERS.ID)
            .fetchOne();
        final Integer userId = id.getValue(Tables.USERS.ID);
        this.dslContext.insertInto(Tables.ORDERS)
            .columns(Tables.ORDERS.USER_ID, Tables.ORDERS.NAME, Tables.ORDERS.PRICE)
            .values(userId, "Banana", 12.5)
            .values(userId, "Apples", 13.0)
            .execute();
        return userId;
    }
}

FusionReactor works with JOOQ the same way as it works with all other frameworks. All generated classes will be stored in the jar file, so you don’t have to do anything else to integrate JOOQ with FusionReactor. After running load testing we can see in the JDBC history tab that JOOQ uses two SQL queries:

How to monitor SQL and ORM frameworks

JOOQ is easier to use than MyBatis because of the compile time checking from the compiler, syntax highlighting from your editor, and auto-mapping from SQL tables to Java classes. It is, however, not as powerful as Hibernate in that you still need to write all queries on your own.

How to monitor SQL and ORM frameworks – Conclusion

All 3 frameworks have their niche among java developers. Still, nowadays, most companies prefer Hibernate to speed up the development time, while other companies prefer lighter frameworks such as JOOQ and MyBatis to have full control over the SQL and, as a result, write more optimized code without relying on SQL generated by JPA. FusionReactor supports all of these frameworks and can give you insides into underlying SQL queries executed by your code and performance metrics for each query. As you have seen, with FusionReactor, it’s really easy to see whether Hibernate behaves the way you expect. If you are interested, please book a demo with us or download a trial.
